Z255 (Model #R560000)
REPAIR ASSEMBLIES ARE SHOWN/REFERENCED BELOW
46
Rotating Jets (5)
BMH Jets (20)
Vertassage Jet
1-Position Air Control Panels (4)
Diverters (2)
Suction Fittings (2)
Ozone Fitting
Duo-Flex Jets (2)
Front Load Filter/Skimmer Assembly
2 Button w/Temp Control Panel
Light
Snap-In Pillows (4)
Product Specification/Serial Number
Plate
Electronic Control Box
(2 Pump/230 Volt)
230 Volt J-Pump/Motor Assembly
230 Volt K-Pump/Motor Assembly
Ozone Generator
NOTE: Effective January 2, 2001
this is the Z255 production configuration.
