Z255 AIR LINE PIPING 50 ITEM          P/N               DESCRIPTION                                                    QTY NOTES:  Unless otherwise specified, all tubing is 3/8” vinyl and all jets are BMH.   Specific lengths are called out for vinyl tubing.  Secure all barb/tubing joints with hose clamp(s), Items 6 and 8. 1 2 3 4 5 6 7 8 9 0825000 H200000 H207000 H203000 H214000 J974000 P600000 J975000 H210000 Bushing, Rdcng, 1” x 1/2” SPG x S Manifold, 4-Port, 3/8” x 1” Ell, 90, 3/8” x 3/4” Barb x SPG Adapter, 3/4” x 3/4” Barb x SPG Cap, 1” Slip Hose Clamp, Dual Wire, 3/4” Tube Ell, Barbed, 3/4” x 3/4” Barb x Slip Hose Clamp, Dual Wire, 3/8” Tube Ell, 90, 3/8” x 1/2”, Barb x SPG 4 7 1 1 2 2 1 50 20 To 1-Position Air Control Panel To 1-Position Air Control Panel To 1-Position Air Control Panel To 1-Position Air Control Panel 1 2 Rotating Jets 1 2 3/4” Vinyl Tubing x 27.00”L. 46.00”L. Rotating Jets 1 2 42.00”L. 24.00”L. 25.00”L. 1 21.00”L. 40.00”L. 44.00”L. 3 8 8 8 8 8 9 9 9 9 9 9 5 8 8 8 8 8 9 9 9 9 4 6 6 7 8 8 8 8 8 9 9 9 9 To Vertassage Jet 2 5 8 9 9 9 10.00”L. 15.50”L. 26.00”L. 22.00”L. 15.00”L. 20.00”L. 24.00”L. 21.00”L. 22.00”L. 11.00”L. 18.00”L. 24.00”L.  14.00”L. 9 24.00”L. 22.00”L. 31.00”L.
