Z255
AIR LINE PIPING
44
ITEM P/N DESCRIPTION QTY
NOTES: Unless otherwise specified, all tubing
is 3/8” vinyl and all jets are BMH. Specific
lengths are called out for vinyl tubing. Secure
all barb/tubing joints with hose clamp(s), Items
7 and 9.
1
2
3
4
5
6
7
8
9
10
0825000
H199000
H200000
H207000
H203000
H214000
J974000
P600000
J975000
H210000
Bushing, Rdcng, 1” x 1/2” SPG x S
Manifold, 8-Port, 3/8” x 1”
Manifold, 4-Port, 3/8” x 1”
Ell, 90, 3/8” x 3/4” Barb x SPG
Adapter, 3/4” x 3/4” Barb x SPG
Cap, 1” Slip
Hose Clamp, Dual Wire, 3/4” Tube
Ell, Barbed, 3/4” x 3/4” Barb x Slip
Hose Clamp, Dual Wire, 3/8” Tube
Ell, 90, 3/8” x 1/2”, Barb x SPG
4
3
1
1
1
2
2
1
50
20
To 1-Position
Air Control Panel
To 1-Position
Air Control Panel
To 1-Position
Air Control Panel
To 1-Position
Air Control Panel
19
9
9
9
9
9
2
4
Rotating
Jets
10
10
10
10
10
10
22.00”L.
9.00”L.
25.25”L.
16.00”L.
24.00”L.
23.00”L.
22.00”L.
19.00”L.
31.00”L.
1
2
5
7
9
9
9
9
10
10
10
10
10
9
8
7
3/4” Vinyl Tubing
x 23.00”L.
46.00”L.
Rotating
Jets
1
2
6
9
42.00”L.
24.00”L.
26.00”L.
22.00”L.
25.00”L.
15.50”L.
11.00”L.
9
9
9
10
10
10
10
1
3
6
10
10
10
9
21.00”L.
40.00”L.
44.00”L.
