Z240/340
DISCHARGE PLUMBING
36
ITEM P/N DESCRIPTION QTY
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
9250000
9231000
0426000
0473000
H197000
H198000
3044000
0522000
5901000
F382000
H203000
J974000
3054000
4649000
P601000
P600000
Repair Kit, Union Adapter
O-Ring, Union
Ell, 90, 2” S x S
Bushing, Rdcng, 2” x 1 1/2”, SPIG x S
Manifold, 8 Port, 3/4” x 1 1/2”
Manifold, 4 Port, 3/4” x 1 1/2”
Compression Ftng, 90, Ell, 1/4”
Ell, 45, 2” S x S
Valve, 2” Swing Check, S x S
Cap, 3/4” Slip
Adapter, 3/4” x 3/4” Barb x SPG
Hose Clamp, Dual Wire, 3/4” Tube
Compression Ftng, Straight, 1/4”
Tube, 1/4” O.D. Flex Nylon x 96.00”L.
Tee, Barbed, 3/4” x 3/4” S x 1” SPIG
Ell, Barbed, 3/4” x 3/4” Barb x Slip
2
2
6
2
1
1
2
1
1
2
2
46
1
1
10
11
NOTES: Unless otherwise specified,
all piping is 3/4” I.D. vinyl tubing. Specific
lengths are called out. All jets referenced
are BMH. Secure all barb fitting/vinyl tubing
joints with one hose clamp, Item 12.
To J-Pump Discharge (Filter)
1
2
3
2” x 6.50”L.
13
3
2” x 8.50”L.
3
2” x 2.50”L.
2” x 19.50”L.
To
Heater
To
Suction
Plumbing7
3
4
10
11
5
6
To J-Pump Discharge
(Whirlpool)
1
9
2” x 2.50”L.
3
8
2” x 6.00”L.
3
4
37.00”L.
37.00”L.
7
14
15
16
4.75”L.
12
11.00”L.
15
62.50”L.
4.75”L.
15
16
77.00”L.
81.00”L.
67.00”L.
15
12
12
12
15
4.75”L.
16
36.00”L.
16
16
16
11
10
73.00”L.
To Ozone
Fitting
39.00”L.
16
12
12
15
15
4.75”L.
16
16
56.00”L.
15
18.75”L.
76.00”L.
4.75”L.
16
15
100.00”L.
30.50”L.
4.75”L.
15
16
16
Jet
#1
#2
#3
#4
#5
#6
#9
#8
#7
#21
#19
#20
#18
#17#16
#15
#14
#13
#12
#11
#10
