Z235/350
SUCTION PLUMBING
32
1
2
3
4
5
6
7
8
9
10
11
9250000
9231000
2901000
P600000
J974000
R745000
0828000
0426000
0473000
3044000
4649000
Repair Kit, Union Adapter
O-Ring, Union
Tee, Rdcng, 2 x 2 x 1, S x S x S
Ell, Barbed, 3/4” x 3/4” Barb x Slip
Hose Clamp, Dual Wire, 3/4” Tube
Drain Valve Assembly
Tee, 2” S x S x S
Ell, 90, 2” S x S
Bushing, Rdcng, 2” x 1 1/2” SPIG x S
Compression Ftng, 90, Ell, 1/4”
Tube, 1/4” O.D. Flex Nylon x 96.00”L.
2
2
1
1
2
1
3
4
1
1
1
6
5
To J-Pump Suction
(Whirlpool)
3/4” I.D. Reinforced PVC
x 29.00”L.
1
2
5
4
3
2” Flex
x 23.50”L.
To Suction
Fitting
2” x 7.00”L.
8
2” x 2.50”L.
7
2” x 9.00”L.
7
9
1 1/2” Flex
x 9.00”L.
2” x 21.00”L.
To Filter/Skimmer
Assembly
8
1 1/2” x 5.50”L.
To J-Pump
Suction
(Filter)
1
2
To Discharge
Plumbing
10
11
8
2” Flex
x 9.50”L.
8
2” Flex
x 26.50”L.
8
2” x 3.00”L.
To Suction
Fitting
ITEM P/N DESCRIPTION QTY
