Z235/350 (Model #S270000)
REPAIR ASSEMBLIES ARE SHOWN/REFERENCED BELOW
30
BMH Jets (18)
Rotating Jet
1-Position Control Panels (4)
Ozone Fitting
Spa Light
Front Load Filter/Skimmer
Assembly
2 Button W/Temp
Control Panel
Suction Fittings (2)
Ozone Generator
(Mounted on inside of upright)
230 Volt J-Pump/Motor
Assembly (Whirlpool)
Electronic Control Box
(2 Pump/230 Volt)
230 Volt J-Pump/Motor
Assembly (Filter)
