Z235/350
AIR LINE PIPING
33
NOTES: Unless specified, all tubing is 3/8” vinyl.
Specific lengths are called out. Jet #15 is a
rotating jet. All others referenced are BMH.
Secure each barb/tubing joint with one hose
clamp, Item 4.
ITEM P/N DESCRIPTION QTY
1
2
3
4
5
6
7
8
H199000
0825000
H214000
J975000
H210000
H200000
H217000
H207000
Manifold, 8-Port, 3/8” x 1”
Bushing, Rdcng, 1” x 1/2” SPG x
S
Cap, 1” Slip
Hose Clamp, Dual Wire, 3/8” Tube
Ell, 90, 3/8” x 1/2”, Barb x SPG
Manifold, 4 Port, 3/8” x 1”
Coupling, Rdcng, 1” x 3/4”, S x S
Ell, 90, 3/8” x 3/4”, Barb x SPG
1
4
3
30
18
3
1
1
To 1-Position
Control Panel
To 1-Position
Control Panel
To 1-Position
Control Panel
To 1-Position
Control Panel
1
2
3
4
Use plugs provided with
manifold
Jet #1
#2
#3
#4
#5
#6
4
5
4
5
5
5
20.00”L.
11.00”L.
15.50”L.
26.00”L.
23.00”L.
20.00”L.
6
3
2
#8
#7
#9
#10
5
5
5
5
4
4
20.50”L.
13.50”L.
19.00”L.
16.00”L.
5
4
5
5
5
4
#11
#12
#13
#14
#15
48.00”L.
52.50”L.
30.50”L.
19.00”L.
23.00”L.
4
8
7
6
2
#17
#16
#19
#18
5
5
4
5
4
5
2
63
41.00”L.
18.00”L.
40.50”L.
60.00”L.
