Z145/345 AIR LINE PIPING 30 1 2 3 4 5 6 H200000 H214000 0825000 7164000 J975000 H210000 4 Port Manifold, 3/8 x 1 Cap, 1” Slip Bushing, Rdcng, 1” x 1/2” SPG x S, Flt Ell, Street, 1/2” 90 Hose Clamp, Dual Wire, 3/8 Tube Barb, 3/8 90 x SPG 1/2 3 3 3 3 22 10 NOTES:  All pipes are 3/8” vinyl tubing. Specific lengths are noted.  Secure all vinyl tubing/barb fitting joints with one hose clamp, Item 5. 25.75”L. To Jet #1 6 6 5 To Jet #3 27.00”L. To Jet #2 6 5 21.50”L. 5 2 1 3 4 To 1-Position Control Panel 55.00”L. 5 To Jet #5 (Located in footwell) 6 To 1-Position Control Panel 4 3 1 2 14.75”L. 30.00”L. 11.00”L. 5 6 To Jet #10 5 6 To Jet #9 5 6 To Jet #8 To Jet #7 6 5 12.00”L. 4 3 To 1-Position Control Panel1 2 20.00”L. 46.00”L. 5 6 To Jet #4 6 To Jet #6 ITEM          P/N               DESCRIPTION                                                                         QTY
