Z140/340 SUCTION PLUMBING 24 1 2 3 4 5 6 7 8 9 10 11 12 13 9250000 9231000 0167000 0239000 0473000 7731000 0157000 P600000 3044000 J974000 0955000 4649000 R745000 Repair Kit, Union Adapter O-Ring, Union Tee, 1 1/2”, S x S x S Ell, 90, 1 1/2”, S x S Bushing, Rdcng, 2 x 1 1/2, SPIG x S Tee, Rdcng, 1 1/2 x 1 1/2 x 1 S x S x S Ell, 45, 1 1/2” S x S Barb, Ell, 3/4 x 3/4 S x 1” SPIG, 90 Compression Ftng, 90, Ell, 1/4” Hose Clamp, Dual Wire, 3/4 Tube Ell, 90, 1 1/2”, Street x Slip Tube, 1/4” O.D. Flex Nylon x 96.00”L. Drain Fitting, Spa 2 2 3 3 2 1 1 1 1 2 1 1 1 1 2 11 1 1/2” x 12.25”L. 3/4” Vinyl Tubing x 26.00”L. 13 10 4 1 1/2” x 2.50”L. 5 To Suction Fitting 1 1/2” x 2.50”L. 3 To Filter/Skimmer Assembly 1 1/2” Flex x 17.50”L. 1 1/2” x 2.50”L. 7 10 1 1/2” Flex x 6.00”L. 4 6 1 1/2” x 2.50”L. 8 To J-Pump Suction 1 2 1 1/2” x 2.50”L. 3 1 1/2” x 16.75”L. 1 1/2” x 3.00”L. 3 To Discharge Plumbing 12 9 4 1 1/2” Flex x 10.50”L. 5 To Suction Fitting ITEM          P/N               DESCRIPTION                                                                 QTY
