Z140/340 DISCHARGE PLUMBING 23 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 9250000 9231000 0955000 0239000 5901000 0473000 0157000 H198000 H197000 J974000 H203000 F382000 P601000 P600000 H205000 3044000 Repair Kit, Union Adapter O-Ring, Union Ell, 90, 1 1/2” Street x Slip Ell, 90, 1 1/2” S x S Valve, 2” Swing Check, S x S Bushing, Rdcng, 2” x 1 1/2” SPIG x S Ell, 45, 1 1/2” S x S 4 Port Manifold, 3/4 x 1 1/2 8 Port Manifold, 3/4 x 1 1/2 Hose Clamp, Dual Wire, 3/4 Tube Barb 3/4 x SPG 3/4 Cap, 3/4, Slip Barb, Tee, 3/4 x 3/4 S x 1” SPIG Barb, Ell, 3/4 x 3/4 S x 1” SPIG, 90 Barb 3/4 90 x SPG 1/2 Compression Ftng, Ell, 90, 1/4” 2 2 3 3 1 1 2 1 1 34 21 2 10 11 1 1 To J-Pump Discharge (Whirlpool) 1 2 5 Drill 3/16” dia. through hole in center of check valve clapper. When installing, ensure arrow points “up”. 6 1 1/2” x 5.00”L. 4 1 1/2” x 16.00”L. 7 1 1/2” x 5.50”L. 1 2 To J-Pump Discharge 3 1 1/2” x 3.50”L. To Discharge Plumbing 1 1/2” x 8.00”L. To Heater 4 9 3 10 10 8 1 1/2” x 6.75”L. 4 12.00”L. 101112 1 1/2” x 23.00”L. 48.00”L. 10 13 4.75”L. Jet #19 Jet #18 117.00”L. 14 13 10 Jet #16 10 14 Jet #15 Jet #14 14 10 38.00”L. 14 Jet #17 10 71.50”L. 15 10 73.00”L. 10 11 12 10 Jet #12 Jet #11 13 10 4.75”L. 14 14 Jet #13 10 30.50”L. Jet #10 13 10 Jet #8 14 4.75”L. Jet #7 13 10 96.50”L. 74.50”L. Jet #9 14 10 Jet #5 18.75”L. 14 4.75”L. Jet #4 13 10 Jet #6 Jet #21 14 10 48.00”L. To Ozone Fitting Jet #3 13 10 55.00”L. 25.00”L. 14 Jet #2 4.75”L. 13 Jet #1 10 32.00”L. 48.00”L. Jet #20 64.00”L. 10 10 55.00”L. NOTES:  Unless otherwise noted, all piping is 3/4” I.D. vinyl tubing. Specific lengths are called out. All jets referenced are BMH. ITEM          P/N               DESCRIPTION                                                                 QTY
