Z140/340 AIR LINE PIPING 25 Use cap and plug provided with manifold To 1-Position Control Panel 1 2 3 4 4 4 4 Jet #4 Jet #6 Jet #5 Jet #21 Jet #9 Jet #7 Jet #8 5 5 5 5 5 5 7.75"L 12.75"L 35.25"L 6.00"L 18.00"L 12.00"L 17.00"L NOTE:  All pipes are 3/8" vinyl tubing. Specific lengths are called out. ITEM          P/N               DESCRIPTION                                                                         QTY 1 2 3 4 5 6 H199000 0825000 H214000 J975000 H210000 H200000 8 Port Manifold, 3/8 x 1 Bushing, Rdcng, 1 x 1/2 SPG x S, Flt Cap, 1" Slip Hose Clamp, Dual Wire, 3/8 Tube Barb 3/8 90 x SPG 1/2 4 Port Manifold, 3/8 x 1 1 5 5 42 21 4 To 1-Position Control Panel Jet #10 Jet #11 Jet #13 Jet #12 5 5 5 5 5 5 4 4 4 4 4 4 5 4 5 To 1-Position Control Panel Jet #2 Jet #3 Jet #1 5 4 5 4 5 4 3 6 2 4 25.75"L 25.75"L 20.75"L To 1-Position Control Panel Jet #19 Jet #20 Jet #18 5 4 5 4 5 4 4 3 6 2 20.50"L 18.75"L 13.75"L To 1-Position Control Panel Jet #14 Jet #17 Jet #16 Jet #15 3 6 2 3 6 2 4 17.00"L 20.00"L 17.00"L 12.00"L 25.00"L 18.00"L 18.00"L 23.00"L
