Z110/310 AIR LINE PIPING 20 1 2 3 4 5 6 7 8 0647000 0825000 H200000 H214000 H217000 H207000 J975000 H210000 Coupling, 1/2” S x S Bushing, Rdcng, 1” x 1/2” SPG x S, Flt 4 Port Manifold, 3/8” x 1” Cap, 1” Slip Reducer Coupling, S x S 1” x 3/4” Barb, 3/8” 90 x 1/2” S x 3/4” SPG Hose Clamp, Dual Wire, 3/8 Tube Barb, 3/8” 90 x SPG 1/2” 1 2 2 1 1 1 18 9 48.00”L. NOTES:  All piping is 3/8” vinyl tubing with specific lengths noted.  Secure all vinyl tubing/barb fitting joints with one hose clamp, Item 7. 8 To Jet #6 8 To Jet #7 41.50”L. 46.75”L. 8 To Jet #5 8 To Jet #8 30.00”L. 4 3 To 2-Position Air Control Panel 2 1 1/2” x 3.00”L. 2 3 5 6 7 42.50” L. 44.00”L. 45.00”L. 8 To Jet #1 62.00”L. 8 To Jet #3 8 8 To Jet #4 To Jet #2 46.50”L. 7 8 To Jet #9 ITEM          P/N               DESCRIPTION                                                                 QTY
