Z101/301
DISCHARGE AND AIR LINE PIPING
14
ITEM P/N DESCRIPTION QTY
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
K449000
0239000
0167000
H198000
H202000
J974000
7355000
D221000
D360000
H203000
7298000
0436000
0455000
C279000
P601000
P600000
U-Bend Fitting
Ell, 90, 1 1/2” S x S
Tee, 1 1/2”, S x S
4 Port Manifold, 3/4 x 1 1/2
Plug, 3/4” Barb
Hose Clamp, Dual Wire, 3/4 Tube
Bushing, Rdcng, 1 1/2” x 3/4” SPIG x S
Ell, 3/4”, 90, S x S
Tee, 3/4”, S x S x S
Barb, 3/4 x SPG 3/4
Ell, Street, 90, 3/4”
Ell, 90, 1/2” S x S
Tee, 1/2”, S x S x S
Adapter, 1/2” S x SPGT
Barb, Tee, 3/4 x 3/4 S x 1” SPIG
Barb, Ell, 3/4 x 3/4 S x 1” SPIG
1
1
1
2
3
16
2
4
2
2
2
4
10
4
3
3
Pump/Motor shown
for reference
1
1 1/2” x 9.38”L.
2
1 1/2” Flex
x 4.00”L.
3
4
4
3/4” Vinyl
x 46.00”L.
5
6
5
5
6
7
7
8
8
11
9
10
6
8
6
14
14
8
9
11
10
6
12
13
14
To 1-Position
Control Panel
To 1-Position
Control Panel
12
13
13
13
13
15
6
6
15
6
6
14
13
13
13
16
6
12
16
6
6
12
13
15
6
16
6
3/4” Vinyl
x 75.00”L.
3/4” Vinyl
x 46.00”L.
3/4” Vinyl
x 30.00”L.
3/4” Vinyl
x 33.50”L.
3/4” Vinyl
x 13.25”L.
NOTE: All jets shown are BMH.
Secure each vinyl tubing/barb
fitting joint with one hose clamp,
Item 6.
3/4” Flex
x 6.13”L.
3/4” Flex
x 6.13”L.
3/4” Flex
x 3.63”L.
(2 Places)
1/2” Flex
x 15.50”L.
1/2” Flex
x 36.00”L.
1/2” Flex
x 3.00”L.
1/2” Flex
x 3.00”L.
1/2” Flex
x 15.50”L.
1/2” x 9.87”L.
(4 Places)
1/2” Flex
x 36.00”L.
1/2” Flex
x 6.75”L.
1/2” Flex
x 34.00”L.
1/2” Flex
x 5.00”L.
1/2” x 16.00”L.
1/2” x 16.00”L.
1/2” x 16.00”L.
1/2” x 16.00”L.
1/2” Flex
x 5.00”L.
1/2” Flex
x 34.00”L.
3/4” Vinyl
x 36.00”L.
1/2” x 1.00”L.
1/2” Flex
x 6.75”L.
14
1/2” x 9.88”L. (4 Places)
